Inverters

Penggunaan inverter On-Grid untuk mengubah arus DC dari panel surya menjadi arus AC. Inverter ini terangkai dalam sistem On-Grid dimana area tersebut harus terhubung dengan jaringan PLN yang ada, dan tanpa menggunaan baterai/aki.

Features Highlights:

• Transformerless
• Maximum efficiency >98.2%
• Triple MPPT
• MPPT Efficiency >99.9%
• RS232/RS485/WiFi interfaces

TECHNICAL SPECIFICATIONS:
INPUT (DC)
Max. DC input power: 66 kW
Max. DC input voltage: 1000Vdc
MPPT tracking voltage range: 250~950Vdc (rated voltage 620Vdc)
Number of MPPT tracking: 3
String of MPPT tracking: 4
Max. input current for each tracking: 40A/40A/40A
OUTPUT
Rated output power: 60 kW
Max. AC output power: 62 kW
Rated output voltage: 400Vac
Output voltage range: 400Vac±20%
AC output topology: 3Ph+N+PE, Transformerless
Grid frequency range: 50/60Hz (±5Hz), (adjustable)
Rated output current: 87A
Max. output current: 90A
Power factor (cos Φ): 0.8 leading - 0.8 lagging
THDI: <2%
SYSTEM FEATURES
Max efficiency: >98.6%
MPPT efficiency: >99.9%
Standby (night time) losses: <2 W
Cooling: Forced air cooling
DC switch: Optional
Communication interface: RS485 standard, external WiFi or Ethernet (optional)
ENVIRONMENTAL
Operating temperature: -25°C~+60°C
Humidity range: 0~95% (non-condensing)
Altitude: 2000m
Noise level: <60dB
Protecting rating: IP65
PHYSICAL
Dimension (W*L*D) in mm: 636 x 958 x 260
Shipping weight: 69kg
Communication interface: RS485 standard, external WiFi or Ethernet (optional)
STANDART
Safety: IEC/EN62109-1,IEC/EN62109-2,VDE0126-1-1, VDE AR N4105, G83/59/EEG2012, AS3100/4777,CEI 0-21,etc.
EMC: EN61000-6-2, EN61000-6-3, EN61000-3-11, EN61000-3-12, etc.

*Specifications subject to change without prior notice
